INTIMA Everolimus-Eluting Coronary Stent System
The INTIMA Everolimus-Eluting Coronary Stent System features ultra-thin 60μm struts with a 3μm uniform drug coating for precise, controlled release. It offers excellent radial strength, minimal recoil, and early endothelialization, ideal for complex coronary interventions. The biodegradable polymer ensures biocompatibility while reducing the risk of in-stent restenosis. Its advanced design allows for smooth navigation through challenging anatomies, making it a reliable choice for both routine and complex procedures.
Technical Specification
Parameter
Specification
Parameter
Specification
Available stent lengths
8, 10, 12, 13, 15, 16, 18, 20, 24, 28, 32, 36, 40, 42, 44 & 48mm
Delivery System Type
Monorail rapid exchange
Available stent diameters
2.25, 2.50, 2.75, 3.00, 3.50, 4.00, 4.50 & 5.00mm
Polymer Type
Biodegradable polymer
Stent Material
L605 Cobalt-Chromium (Co-cr) alloy
Nominal Pressure
8 Bar
Stent Design
Open and closed hybrid cell design
Rated Burst Pressure
16 Bar/ ATM up to 4.00mm diameter
Stent Platform
Cobal + C
Guidewire Compatibility
0.014”
Stent foreshortening
<2%
Guiding Catheter Compatibility
5F
Stent Recoil
<4%
Delivery System
Hydrophilic coated
Stent struct thickness
60µm
Tip Entry Profile
0.018”
Drug
Everolimus
Proximal Shaft Diameter
0.76mm
Coating Thickness
3µm
Distal Shaft Diameter
0.89mm
Parameter
Available stent lengths
Available stent diameters
Stent Material
Stent Design
Stent Platform
Stent foreshortening
Stent Recoil
Stent struct thickness
Drug
Coating Thickness
Specification
8, 10, 12, 13, 15, 16, 18, 20, 24, 28, 32, 36, 40, 42, 44 & 48mm
2.25, 2.50, 2.75, 3.00, 3.50, 4.00, 4.50 & 5.00mm
L605 Cobalt-Chromium (Co-cr) alloy
Open and closed hybrid cell design
Cobal + C
<2%
<4%
60µm
Everolimus
3µm
Parameter
Delivery System Type
Polymer Type
Nominal Pressure
Rated Burst Pressure
Guidewire Compatibility
Guiding Catheter Compatibility
Delivery System
Tip Entry Profile
Proximal Shaft Diameter
Distal Shaft Diameter
Specification
Monorail rapid exchange
Biodegradable polymer
8 Bar
16 Bar/ ATM up to 4.00mm diameter
0.014”
5F
Hydrophilic coated
0.018”
0.76mm
0.89mm
